Trough-and-Pan Liquid Distributor

The XINYU HUACHUANG Trough-and-Pan Liquid Distributor is an advanced liquid distribution system specifically engineered for large-diameter packed towers. Combining the high-capacity trough design with the superior collection capabilities of a pan, this liquid distributor ensures optimal vapor-liquid contact and prevents wall-flow. It guarantees uniform liquid distribution even under fluctuating flow rates, maximizing separation efficiency in critical distillation and absorption processes.

Working Principle

● Core Mechanism: The Liquid Distributor operates by collecting incoming liquid in a primary pan, which then evenly feeds into parallel troughs. Liquid flows through these troughs and is discharged onto the packing bed through precisely calibrated holes or weirs. This dual-stage design ensures exceptional distribution uniformity and high operational flexibility.

● Materials: Constructed from premium materials including SS304/316L, Hastelloy, or specialized fluoropolymers (PTFE/PFA) to ensure durability and corrosion resistance in harsh environments.

● Process Integration: This versatile Trough-and-Pan Liquid Distributor pairs seamlessly with structured and random packing internals. It is ideally suited for high-purity fractional distillation, gas absorption, and solvent recovery processes, and integrates perfectly with automated reflux ratio control systems.

Technical Specifications

How to Choose Right?

● Define Tower Diameter & Liquid Load: Accurately determine the tower cross-sectional area and expected liquid flow rate. This is critical for sizing the trough width, hole diameter, and weir height of the Trough-and-Pan Liquid Distributor to prevent flooding or dry spots.

● Assess Feedstock Purity: If the feed contains particulates or is prone to fouling, prioritize a trough-pan design with larger orifices or weir-type discharge to prevent clogging.

● Material Compatibility: Select the appropriate metallurgy or polymer based on the chemical properties of your mixture. Standard SS316L is suitable for most organic solvents, while highly corrosive acids require Hastelloy or PTFE.

● Operational Flexibility: If your process experiences significant flow rate fluctuations, ensure the selected Trough-and-Pan Liquid Distributor has a wide operational turndown ratio to maintain uniform distribution at low loads.
