High And Low Temperature Wire Bending And Winding Test Bench

The XINYU HUACHUANG High And Low Temperature Wire Bending And Winding Test Bench is an advanced, industrial-grade testing apparatus specifically engineered to evaluate the mechanical and electrical integrity of wires and cables under extreme thermal conditions. Designed to simulate harsh operational environments, this High And Low Temperature Wire Bending And Winding Test Bench precisely combines cyclic bending or winding actions with precise temperature control (ranging from deep cold to high heat). Equipped with intelligent PLC automation and multi-level safety interlocks, it ensures safe, unattended long-term operation while delivering highly reproducible fatigue and insulation data for R&D, quality control, and industry certification.

What is a High And Low Temperature Wire Bending And Winding Test Bench?

A High And Low Temperature Wire Bending And Winding Test Bench is a specialized combined-environment testing system that integrates a programmable thermal chamber with a mechanical bending or winding mechanism. By simultaneously applying controlled mechanical stress and extreme temperatures, this High And Low Temperature Wire Bending And Winding Test Bench accurately simulates real-world conditions such as automotive wiring harnesses in engine bays, aerospace cables in high-altitude cold, and industrial cables in heated machinery. It is critical for identifying failure mechanisms like insulation cracking, conductor fatigue, and material embrittlement under dynamic thermal loads.

Why This One?

● Combined Environment Simulation: Precisely synchronizes extreme temperatures (-70℃ to +200℃) with cyclic bending or winding to replicate real-world thermal-mechanical stresses.

● High-Precision Control: Features advanced PID temperature controllers and servo-driven mechanical actuators for accurate, stable, and repeatable test conditions.

● Intelligent Data Acquisition: Integrated PC software automatically records real-time curves (Temperature-Time, Bend Count-Resistance), detects open circuits, and generates comprehensive test reports.

● Robust & Safe Construction: Built with high-quality thermal insulation, corrosion-resistant interiors, and multi-level safety interlocks to protect both the equipment and operators.

● Customizable Fixturing: Offers specialized mandrels, clamps, and bending arms to securely hold various wire diameters and cable geometries without slippage.

Technical Specifications

Where does it apply?

● Automotive Industry: Testing engine bay wiring harnesses, EV charging cables, and battery interconnects for thermal fatigue and vibration resistance.

● Aerospace & Aviation: Evaluating high-altitude cold resistance and engine heat tolerance of aircraft wiring and sensor cables.

● Industrial Equipment: Assessing the durability of robot cables, drag chain cables, and heating element wires in extreme manufacturing environments.

● Consumer Electronics: Validating the cold-weather flexibility and heat resistance of power cords, USB cables, and appliance internal wiring.

● Wire & Cable Manufacturing: Routine quality control and R&D validation for insulation materials and conductor stranding processes.

Steps in Manufacturing

1. Requirement Confirmation: Analyze the client's specific testing standards, wire/cable specifications, and required temperature/bending parameters to customize the technical proposal.

2. Design & Engineering: Finalize mechanical CAD drawings, thermal chamber design, and electrical schematics for the High And Low Temperature Wire Bending And Winding Test Bench.

3. Precision Manufacturing: Machine the rigid main frame, assemble the high-precision servo drive system, and integrate the thermal chamber with insulation and heating/cooling elements.

4. Software Development: Program and calibrate the data acquisition software to ensure accurate curve plotting, automated cycle counting, and resistance monitoring.

5. Factory Testing: Conduct rigorous thermal uniformity calibration, mechanical load testing, and actual wire specimen testing to verify accuracy and safety interlocks.

6. Packaging & Shipping: Securely pack the test bench in export-standard wooden crates with protective foam, and provide comprehensive English manuals and video installation guides.

After-Sales Service & Support

At XINYU HUACHUANG, we are committed to providing comprehensive and reliable after-sales support to ensure the continuous and efficient operation of your equipment. Our dedicated service team is always ready to assist you.

Comprehensive Warranty Coverage

We proudly offer a two-year warranty for our equipment. During this period, we provide free maintenance and repair services for any quality-related issues, excluding those caused by improper operation, unauthorized modifications, or force majeure. For equipment beyond the two-year warranty period, we continue to offer lifelong maintenance services, charging only the cost of replacement parts and labor.

Rapid Response Mechanism

We offer 7×24 hours professional engineering telephone support. Upon receiving a fault notification, our technical team will respond within 24 hours and provide a viable solution. If on-site service is required, our professional engineers will arrive at your facility within one week. In special circumstances where the equipment cannot be repaired, we will unconditionally replace it with a new unit or provide a substitute unit during the two-year warranty period, or take necessary measures to restore normal operation.

Frequently Asked Questions (FAQ)

Q1: How does this test bench simulate real-world cable installation and operating conditions?

A: The bench integrates a programmable thermal chamber with a mechanical bending or winding mechanism. By simultaneously applying controlled mechanical stress and extreme temperatures—both high and low—it replicates conditions such as automotive wiring harnesses in hot engine bays, aerospace cables exposed to high-altitude cold, and industrial cables near heated machinery.

Q2: What failure mechanisms does combined thermal-mechanical testing reveal in wires and cables?

A: The test identifies insulation cracking caused by embrittlement at low temperatures, insulation softening and deformation at high temperatures, conductor fatigue from repeated bending under thermal stress, and delamination between conductor and insulation layers. These failure modes often remain undetected in ambient-temperature-only tests.

Q3: What temperature range can the thermal chamber achieve?

A: The programmable thermal chamber covers a wide range from sub-zero temperatures (typically -40°C or lower) to elevated temperatures (typically +200°C or higher). This allows testing across the full spectrum of environmental conditions that cables may encounter in automotive, aerospace, and industrial applications.

Q4: Can the bench perform both bending and winding tests on the same platform?

A: Yes. The mechanical system supports both bending tests—where the wire is bent to a specified radius and straightened repeatedly—and winding tests—where the wire is wrapped around a mandrel of defined diameter. Both modes operate inside the thermal chamber under controlled temperature conditions.
