Multi-Channel Reaction Evaluation Pilot Unit

The XINYU HUACHUANG Multi-Channel Reaction Evaluation Pilot Unit is an advanced, high-throughput laboratory and pilot-scale system engineered to accelerate R&D in heterogeneous catalysis. Designed to maximize testing efficiency, this unit integrates multiple independent parallel reaction channels into a single footprint. It allows researchers to simultaneously evaluate different catalyst formulations or varying operating conditions under identical parameters. Equipped with precise mass flow controllers, multi-zone heating, and intelligent PLC automation, the Multi-Channel Reaction Evaluation Pilot Unit significantly reduces experimental cycles while ensuring highly reproducible, comparable data for industrial scale-up.

Working Principle

● Core Mechanism: The unit operates on a parallel plug-flow principle. Reactants are precisely metered via mass flow controllers and distributed into multiple independent reactor tubes. The gas-solid or liquid-solid reactions occur within the fixed catalyst beds, and products are analyzed online to evaluate conversion rates and selectivity.

● Reactor Materials: To accommodate diverse chemical environments, we offer premium reactor materials including high-purity Quartz (for corrosion resistance and visibility), SS316L (for standard high-pressure applications), Hastelloy, and Inconel (for extreme high-temperature and highly corrosive conditions).

● Process Integration: This versatile Multi-Channel Reaction Evaluation Pilot Unit pairs seamlessly with various catalytic processes, including selective catalytic reduction (SCR), Fischer-Tropsch synthesis, methanol-to-olefins (MTO), VOC oxidation, and biomass gasification. It also integrates flawlessly with online analytical instruments like GC, FTIR, or MS for real-time multi-channel data acquisition.

Technical Specifications

How to Match Your Testing Requirements with Our Unit

● Define Your Process: Clearly identify the reaction type (e.g., highly exothermic, high-pressure hydrogenation) to determine the required temperature, pressure, and reactor material.

● Channel Quantity: Determine your required testing throughput. We can customize the unit with 4, 6, 8, or more parallel channels based on your specific laboratory R&D needs.

● Parallel vs. Series: Choose parallel operation for comparing different catalysts under identical conditions. Choose series connection if you need to simulate multi-stage industrial reactors or study intermediate products.

● Analytical Needs: Determine the number of sampling points. Multi-channel reactors require a multi-port sampling valve or dual GCs for simultaneous online analysis.

● Scale-Up Consideration: If future scale-up is planned, select a reactor diameter and catalyst bed volume that aligns with your pilot-plant dimensions to ensure kinetic data transferability.

Product Comparison

Why Choose Us

● Direct Factory Pricing: As the original manufacturer, we eliminate middlemen, offering highly competitive pricing without compromising on quality.

● Deep Customization Capability: From reactor metallurgy to control logic, our engineering team tailors every detail to your specific catalytic research needs.

● Industrial-Grade Reliability: Built with top-tier components (e.g., premium MFCs, industrial PLCs) and rigorous factory testing, ensuring long-term stability for unattended 24/7 operation.

● Comprehensive After-Sales Support: We provide lifetime technical support, English video tutorials, and remote troubleshooting via video calls to ensure your R&D never stops.

● ISO-Certified Quality: Every unit undergoes strict pressure testing, leak detection, and temperature uniformity calibration before shipment, backed by our ISO quality management system.
